Stagehand 17206 Pilewind Winch

The Stagehand 17206 Pilewind Winch is a set-up hoist. Perfect for vertically lifting curtains, lighting equipment, and sets in theatres and venues. The Stagehand 17206 has been designed with safety in mind to conform to EN 17206:2020 for UC1 and UC2. We have a list of standard models, but custom options are available.

Features

  • WLL: 300kg - 1000kg
  • Lines : 3 - 6
  • Speed: upto 0.2m/s
  • Travel: Various models upto 22m
  • Wire Rope: 5mm or 6mm
  • Maximum 2.2kW motor size
  • Load cell for overload prevention
  • Two independent Limit Switches
  • Local E-Stop
  • On-board Control System

Optional Extras

  • Soft start/stop & variable speed
  • Absolute Encoder
  • Slack line detection
  • Motor overheat detection
  • Brake release sensors

Explore:

Datasheet Brochure
